W-Light Surge Super Slim 8.5 5800Lm/5000K
Ultra-slim 4300-lumen LED bar with dual park lights and IP69K durability. Read more
Product overview
W-Light Surge Super Slim 8.5 delivers 4300 tested lumens in a sleek, low-profile design. Featuring dual-color park lights and IP69K protection, it's built for vehicles with limited space but no tolerance for compromise.
- kid_starLow profile
- kid_starParking light
What makes it special
- starUltra-slim body fits tight mounting spaces
- star4300 tested lumens and 361 m beam in double setup
- starDual park light: switch between amber or white
- starIP68/IP69K durability for extreme conditions
- starPart of Surge series with multiple length options!
Specifications
- Dimensions
- 33 x 214 x 59 mm
- IP Classification
- IP68/IP69K
- Voltage
- 9-36 V
- Power Consumption
- 5 W
- Lumens (factory)
- 5800 Lm
- Lumens (tested)
- 4300 Lm
- Light Temperature
- 5000 K
- Lux
- 1 lux @ 235 m (double: 361 m) lux
- Shape
- Bar/Panel
- Color
- Black
- Plug Type
- 4-pin DT
- EAN
- 6438255038761
- Certificates
- R148, R149, R10
- Warranty
- 24 months
- SKU
- 1605-NS3876
About W-Light Surge Super Slim 8.5 5800Lm/5000K
The W-Light Surge Super Slim 8.5 is designed for drivers who need serious lighting performance in tight spaces. With just 33 mm body height and a beam reach of 235 meters, this compact powerhouse offers the same quality and safety approvals as larger units—without the bulk.
Despite its size, the bar delivers 5800 theoretical and 4300 tested lumens of neutral white 5000K light. Equipped with dual-color park lighting (amber and white), the Surge also helps you stand out and stay visible, whether you’re on the road or on a site.
Built to handle the harshest environments, the IP68/IP69K-rated aluminium housing and polycarbonate lens shrug off water, dust, snow, and vibration. A 4-pin DT connector and 2.2 m cable allow flexible, reliable integration with your vehicle’s electrical system.
The Surge Super Slim series includes multiple sizes, making it easy to match light output and fit to the job at hand. This 8.5-inch version is ideal for quads, ATVs, work vans, or any setup where clearance is limited but performance matters.
Other info:
- Model name: Surge Super Slim 8.5
- LED type: 6 x LED
- Park light: Dual-color (amber and white)
- Housing: Aluminium
- Lens: Polycarbonate
- Series variants: 8.5, 20, 20 AMT, 30, 40
- Weight: 2.00 kg (net)
Get a good look at W-Light Surge Super Slim 8.5 5800Lm/5000K
Installation Guidelines
The product comes with all necessary instructions.
However, we recommend consulting a professional to ensure proper installation.
